ProfiCAD is designed for drawing electrical and electronic diagrams, schematics, control circuit diagrams, and can also be used for pneumatics, hydraulics, and other types of technical diagrams.
ProfiCAD generates a bill of material, a list of wires, a list of terminals, a list of cables, and other important parts of an electrical project.
The program comes with more than two thousand symbols. You can easily create your own symbols in the symbol editor.
The title block designed in accordance with ISO 7200 can be easily adapted, for example by inserting the logo of your company. Alternatively, you can create your own title block in the title block editor.
The program supports cross-references between wires and between symbols belonging to one component (e.g., relay coil + contacts). A linked symbol on a different page can be accessed by clicking on the cross-reference.
The program supports drawing cable symbols. A cable listing is available, providing an overview of their cores, cable properties, and connected devices. Thanks to the terminal list, you have an overview of all project terminals and the cables and devices connected to them.
Some advanced features include automatic numbering of symbols, drawing of striped wires, instant symbol search, automatic insertion of symbols into a circuit, and others.
